IK Multimedia iRig Stream Pro

Connect more with the world:

The original iRig Stream offered groundbreaking features that made it an overnight must-have for millions of creators.

Now iRig Stream Pro takes your podcasting and streaming to an all-new level.This 24-bit, 96 kHz audio interface for iPhone, iPad, Android and Mac/PC offers an XLR mic preamp, stereo RCA, TRRS and device inputs (loopback) – plus advanced routing, convenient controls and total portability.

It’s everything you need for professional quality streaming, right in the palm of your hand

Features:

Type : 2 in/2out or 4 in/2out

Conversion : 24-bit A/D, 24-bit D/A

Sampling Rate : 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz

Power : USB bus powered. 48V operations with iOS devices require battery or DC IN. When connected to an external PSU (iRig PSU 3A, not included), iRig Stream Pro charges the connected iOS lightning device.

Metering : 3x LEDs for overall streaming signal. Peak meter for Mic/Inst input.

Device Connection : mini-DIN

Dimensions : 123 mm/4.84” x 67 mm/2.63” x 40 mm/1.57”

Line input:

Connector : 2x RCA (unbal.) Left/Right

Nominal Input Level : -10 dBV

Head Room : 10 dB – Level @ max

Input Impedance : 16.5k Ohms

Frequency Response : from 20 Hz to 20 kHz (-1.5 dB)

Microphone Input:

Microphone Input : balanced, XLR. Pin 2 : hot / Pin 3 : cold / Pin 1 : ground

Microphone Input Level : from 3.8 mV RMS to 388 mV RMS

Microphone Input Impedance : approx 2 kOhms

Analog Gain Range : 40 dB

Phantom Power : +48 V ± 4 V

Frequency Response : from 20 Hz to 20 kHz (-1 dB) Gain @ min, from 20 Hz to 20 kHz (-3 dB) Gain @ max

Instrument Input:

Instrument Input : unbalanced, Hi-Z, TS 1/4” Jack, Tip : signal / Shield : ground

Instrument Input Level : from 70 mV RMS to 1.8 V RMS

Instrument Input Impedance : 1M Ohms

Analog Gain Range : 28 dB

Frequency Response : from 20 Hz to 20 kHz (-1 dB) Gain @ min, from 20 Hz to 20 kHz (-3 dB) Gain @ max

Headset/Phones:

Connector : 1/8” TRRS jack (CTIA wiring standard)

Supply voltage : > 2,5 V

Microphone gain : Adjustable with numbered thumbwheel

Frequency Response : 20 Hz – 20 kHz

Headphone Level control : numbered thumbwheel

Battery Life:

Phantom power On with iOS device : up to 20 hours (Alkaline batteries), with mic input connected to 3.1 mA phantom powered load
