Zoom V6-SP Vocal Effects Processor Pedal

Product Description

Details :

Unleash Your Voices

Packed with professional vocal effects, built-in looper, and our new Formant Pedal, no matter what style you sing the V6 will take your music to the next level

WHAT’S INCLUDED WITH THE V6-SP

V6-SP Vocal Processor

AD-16 AC Adapter

Quick Guide

Patch Memory List

OPTIONAL V6 ACCESSORIES

SGV-6 Shotgun Microphone

FP02M Expression Pedal

CBR-16 Carrying Bag

Let’s Hook Up

XLR Mic Input

Phantom Power Switch

Control Pedal Input

USB Output/Audio Interface

Headphone Out/Volume Control

XLR Output

DC Power In

Back Panel of V6 with an A-G letter key

Product highlight of V6 focus on Voice

Find Your Voice:

Select your desired Voice Effect from 12 different options ranging from the Unison Effect to Octave, Up/Down, to Vocoder. You can even chose Pitch Correct to deliver your EDM sound.

Checkout Vocoder, Whistle, and Talkbox samples here.

Product highlight of V6 focus on Harmony

Craft Your Harmony

Add up to two backing vocals and create your perfect three-part harmony. Based on the key you’ve chosen, the V6 creates the appropriate harmonic intervals.

Download the V6 Harmony Chart here.

Checkout dry vocals compared to Oct Up High Harmony Patch and Choir Harmony Patch here.

Product highlight of V6 focus on Effects

Extra Sauce

Choose from 10 popular studio effects including classics such as Delay, Chorus, and Reverb. Or go modern with effects like Telephone and Beatbox.

Checkout Chorus, Beatbox, and Telephone samples here.

Features:

V6 offers over 10 studio-grade effects

Simultaneously use up to three vocal processors from the Voice, Harmony and Effect sections

Formant Shift pedal for adjusting your vocal character in real time

Looper for recording up to 3:30.

40 preset patches created by professional vocalists and audio engineers

100 memory locations for storing user-created patches

Built-in compressor for optimizing input signal levels

Built-in Enhancer for optimizing input signal frequencies via equalization and de-essing

USB 2.0 audio interface capable of recording up to 16/24/32-bit, 44.1 kHz

USB port for firmware updates, power and audio recording

Line output for connecting to external mixing consoles

Headphone output with dedicated volume control

Runs for 3.5 hours on four AA batteries

Included AC adapter

Optional expression pedal offers advanced control over effects parameters

Specs:

V6-SP VOCAL PROCESSOR

VOICE SECTION 12 types

EFFECT SECTION 10 Types

HARMONY SECTION 5 Types

NUMBER OF PATCH MEMORIES 100

SAMPLING FREQUENCY 44.1 kHz

A/D CONVERSION 24-bit 128× oversampling

D/A CONVERSION 24-bit 128× oversampling

SIGNAL PROCESSING 32-bit

FREQUENCY RESPONSE 20 Hz–20 kHz (+1 dB/−3 dB) (200 kΩ load)

DISPLAY 2-digit 7-segment LED

INPUT:

MIC IN XLR jack Input gain: +3 – +40 dBMaximum input level: +4 dBuInput impedance: 3 kΩ or higher (1 kHz)Phantom power: +48 V

OUTPUTS:

OUTPUT XLR jack Maximum output level: +8 dBuOutput impedance: 50 Ω (HOT-GND, COLD-GND, 1 kHz)100 Ω (HOT-COLD , 1 kHz)GROUND LIFT (switchable)

PHONES Stereo mini jack Maximum output level:20 mW + 20 mW (into 32 Ω load)

EQUIVALENT INPUT NOISE (WHEN PHANTOM POWER OFF) –125 dBu or less (A-weighted, 150 Ω input, +40 dBu input gain)

NOISE FLOOR (RESIDUAL NOISE) –75 dBu

CONTROL INPUT FP02 input

POWER AC adapter (9 V DC 500 mA, center negative) (ZOOM AD-16) 4 AA batteries (about 3.5 hours continuous operation time when using alkaline batteries)

USB Connector: Micro USB Audio interface operation: 2-in/2-out USB2.0 Full Speed, 44.1 kHz, 16/24/32-bit• Power can also be supplied through the USB port.• When using a cable designed only for power, other USB functions cannot be used.

EXTERNAL DIMENSIONS: 181 mm (D) × 320 mm (W) × 77 mm (H)

WEIGHT: 1.56 kg (excluding batteries
